7. Specifications
Model Name MCU-100P
Product Name Multi-Camera Control Unit
Input / Output Interface
RJ45 x 4
CV x 1
Camera Adapter AD-1P
Remote Control Interface Ethernet
Number of Cameras Controlled 4
Maximum Transmission Distance Up to 300m (CAT-5 or CAT6)
Supported Functions
Record and Playback
Camera User Memory Functions
Camera OSD Menu Navigation
Shutter Speed and Degree Functions
Iris Adjustment
AWB & ABB Functions
White Balance A / B and Preset Functions
Camera Knee & Bars Functions
Camera Gain Adjustment
RGB Black Level / R&B Gain and Master Pedestal Controls
Compatible Camera Models
AG-HPX255, AG-HPX300, AG-HPX301, AG-HPX302, AG-
HPX304, AG-HPX370, AG-HPX370P, AG-HPX371, AG-HPX372,
AG-HPX500, AG-HPX502, AG-HPX600, AG-HPX600P, AJ-
HDX900, AJ-HPX2700, AJ-HPX2700G, AJ-HPX3000, AJ-
HPX2000*, AG-HPX380, AG-HPX3100, AJ-PX800G, AJ-PX500,
AG-HPX393
Power Supply DC 12V / 0.5A
Power Consumption 6 W
Dimensions 95mm (W) x 208mm (H) x 65.5mm (D)
Weight 350g
