Page #11 background image
11
3.2 Control Keyboard
Keyboard Control Guide
Power switch
Use this switch to power the MCU-100P On or Off.
Camera selection
Select the button for the camera that you wish to control.
Camera
Selection
Memory
Store
Recorder
Control
Selection
Save
Menu
Gain
Camera Video
Signals Enable
White / Black
Balance
USB for F/W
Upgrade
IRIS
Adjustment
LED Display
Check

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datavideo MCU-100P and is the answer not in the manual?

Datavideo MCU-100P Specifications

General IconGeneral
Power Supply12V DC
Weight1.2 kg
Number of Controllable Cameras4
Supported CameraDatavideo
Control InterfaceRS-422
Outputs1 x Audio
