Maintenance M7/M7L/M7LT Modular Satellite Modem
3-58 M7/M7L/M7LT - Rev. 0.05
I7 Interface Parameters
Representation
Type
Entry
Description
Status Hardware S/N
1016001
Read Only
N/A
Indicates the serial number of the
active interface
IP Control Mode
Full Access
Selection
0 = Disable,
1 = Read Only,
2 = Full Access
Send WAN Protocol
M7 HDLC
Selection
0 = M7 HDLC
1 = M500 HDLC
IP DHCP
Enabled
Selection
0 = Disable, 1 = Enable
IP Address
192.168.100.001
Numeric
IP v4 IP Address format
IP Network Mask
255.255.255.0
Numeric
IP v4 IP network mask
format
IP MAC Address
00:80:A8:00:25:6C
Read Only
N/A
IP Q7 Reset Control
Watchdog
Selection
0 = Watchdog,
1 = Manual,
2 = Force Reboot Now
Selects the reset control of the I7
Controller.
IP Q7 ID
PQ7-M101G-R10-2
Read Only
N/A
I7 Controller Model Number
IP Q7 Software Ver
Vyatta-3.03
Read Only
N/A
I7 Controller software type and
version
Stats Send Data PPS
0.015 kpps
Read Only
Stats Send Data Packets
3.125E3
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Send Data Bytes
2.000E5
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Send Data Usage
12.66%
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Send MCC Packets
0
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Send MCC Bytes
0
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Send MCC Usage
0.00%
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Send Idle Packets
2.156E4
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Send Idle Bytes
1.380E6
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Send Idle Usage
87.33%
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Send Total Packets
2.468E4
Read Only
Press “Edit” then "Enter"
to reset the counter
