M7/M7L/M7LT Modular Satellite Modem Maintenance
M7/M7L/M7LT - Rev. 0.05 3-59
I7 Interface Parameters
Representation
Type
Entry
Description
Stats Send Total Dropped
1.282E3
Read Only
Press “Edit” then "Enter"
to reset the counter
(Future Option) Indicated the
total number of packets dropped
for all data types
Stats Send Total PDR
1.641E-5
Read Only
Press “Edit” then "Enter"
to reset the counter
(Future Option) Indicated the
total packet dropped rate for all
data types.
Stats Send Total Sec.
208
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv Data PPS
0.015 kpps
Read Only
Stats Rcv Data Packets
3.125E3
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv Data Bytes
2.000E5
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv Data Usage
12.66%
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv MCC Packets
0
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv MCC Bytes
0
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv MCC Usage
0.00%
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv Idle Packets
2.156E4
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv Idle Bytes
1.380E6
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv Idle Usage
87.33%
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv Total Packets
2.468E4
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv Total Erred
10
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv Total PER
4.051E-7
Read Only
Press “Edit” then "Enter"
to reset the counter
Stats Rcv Total Sec.
208
Read Only
Press “Edit” then "Enter"
to reset the counter
MCC Mode
Full Access
Selection
0 = Disable
1 = Read Only
2 = Full Access
Sets the rights of the MCC
channel.
MCC Protocol
M7 Binary Packet
Selection
0 = M7 Binary Packet
MCC Send Rate Limit
10.0 kbps
Numeric
Entered in kbps up to the
maximum rate of the
satellite data rate.
Sets the maximum rate of the
MCC channel
