Power Connection
Davey ProMaster is suitable for connection to a nominal 240 volt / 50Hz power
supply, and is equipped with a cable and 3 pin plug. If a power outlet is not
available within 3 metres of the pump, a 3 pin power point in a safe, dry place
may need to be provided by an electrician. Extension cords are unsafe around
pools - and shall be avoided. If the supply cord of this product is damaged it must
be replaced by the dealer or manufacturer, with genuine Davey spares.
This ProMaster pool pump incorporates motor overload detection designed to
protect the motor from overheating. If the motor gets too hot during operation, its
operating speed will reduce to bring it within an acceptable operating temperature
and then will speed up to the originally set speed.
To reset the motor, switch the power off for 30 seconds, and then return the power
from the mains switch.
All installations must be fitted with earth leakage or residual current
protection devices, having a rated residual operating current not
exceeding 30mA.
CAUTION:
In the interest of safety, we advise that all brands and types of pool pumps
must be installed in accordance with AS/NZS 3000 known as the
national wiring rules or equivalent local standards. All electrical
installations must be carried out by a qualified electrician.
If the pump and filter are located below pool water level, it is necessary to
fit isolating valves in the pipe between the pump and skimmer box and in
return pipe from the filter to the pool.
The fittings on this product are constructed of ABS. Some PVC jointing
compounds are incompatible with ABS. Check compound suitability
before use.
Warning! Ensure that an electrical isolation switch is located with easy
access so that the pump can be switched off in an emergency.
Warning! Power supply to this pump needs to be through an
RCD, having a rated leakage current not exceeding 30mA.
MSZ 2364-702:1994 / MSZ 10-533 1/1990
UNE 20460-7-702 1993, REBT ITC-BT-31 2002
