Installation of the Davey ProMaster VSD Pool pump with Bluetooth
Location
The pump should be located as close to the water as practicable and mounted on
a firm base in a well-drained position, high enough to prevent any flooding. It is the
installer’s/owner’s responsibility to locate the pump such that the nameplate can be
easily read and the pump can be readily accessed for service.
1. Do not install 90° elbows directly into pump inlet. Elbows should be no closer
than 250mm to the inlet.
2. Flooded suction systems should have gate valves installed on suction and
discharge pipes for maintenance, however, the suction gate valve should be
no closer than 250mm from the inlet.
3. Use a check valve in the discharge line when using this pump for any
application where there is significant height to the plumbing after the pump.
4. Be sure to install check valves when plumbing in parallel with another pump.
This helps prevent reverse rotation of the impeller and motor.
