23
You should carry out the following
steps as per the instructions for
Installation Type 1
Step 2Work out the position of your
RainBank with regard to distance to
power. The float switch lead is not an
issue here.
Step 4Align the RainBank for easy
fitting to the plumbing. Fit Davey wall
bracket.
Step 5 – Connect RainBank to your
submersible pump as per instructions on
page 25.
Step 6 – Connect the RainBank to the
plumbing.
Step 7 – Connect all leads (no float
switch lead to plug in)
Step 8Test the unit - page 21
INSTALLATION TYPE 4
Below ground tank with pump
above tank and suction lift
IMPORTANT
Under AS/NZS 3500.1 collecting/
storing rainwater in a partially buried
tank is considered a medium level
hazard. Even though RainBank has a
built-in dual check back flow valve
you may be required to fit additional
backflow protection valves to satisfy
this requirement.
NOTE: To allow for the correct operation
of your RainBank and for
movement of the tank and pump
which may occur over time, the
suction pipe must have a length
of flexible suction hose from
pump to top of tank. This hose
can be braided hose, reinforced
suction hose or polythene pipe at
least 1 metre in length.
The following sections of the Type
1 installation instructions are
applicable to Type 4 installations.
Step 1 – Evaluate and select the best
pump site as close to the water source
and water level as possible.
Step 2Work out the position of
your RainBank with regard to distance
to power.
!
FV
Mains In
To House
