Position of the camera
The camera can be mounted on the right or left side of the projector:
Size of the scan object / scan area Position of the camera (seen from rear)
up to 110 mm to the left of the projector
110 to 350 mm optional, better to the left
from 350 mm to the right of the projector
If necessary, mount the camera slide to the corresponding side. The exact position of the slide (distance
from the projector) is set later in operation. The distance between the camera and projector optics will be
similar to the size of the object / region to be scanned.
