DAVIS Vantage Pro2 User Manual

Finding the Correct Serial Port
28
Finding the Correct Serial Port
The software includes a procedure for locating the serial port to which your
station is connected or determining whether that serial port is working. Using
the Loopback command (as opposed to Test) will help you find the correct
port and determine whether the serial port or the data logger is causing a com-
munication problem. The loopback function will also detect and report the
presence of any modems.
To use this procedure, you will need the loopback connector (the
short cable with a phone jack on one end and a red plastic tip on
the other) supplied with Weatherlink.
1. If necessary, disconnect the cable between your station and the
adapter connected to the COM port.
2. Insert the loopback connector into the adapter.
3. Select Communications Port from the Setup menu.
The Communications Port dialog box displays.
4. Click Loopback.
The software searches all standard serial ports and inform you of the COM
port at which the loopback connector is located.

DAVIS Vantage Pro2 Specifications

General

Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Barometric Pressure Range	16.00 to 32.50 inHg (540 to 1100 hPa)
Rain Collector Type	Tipping bucket
Wind Speed Range	0 to 200 mph (0 to 322 km/h)
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Wind Direction Resolution	1°
Wind Direction Accuracy	±3°
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Sensor Accuracy	±5%
UV Index Range	0 to 16
UV Index Accuracy	±5%
Wireless Transmission Range	Up to 1000 ft (300 m)
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100%
Humidity Accuracy	±3%
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Measurement Accuracy	±4%
Wind Direction Range	0 to 360°
Power Supply	Solar powered with battery backup
