DAVIS Vantage Vue Manual

1
Welcome to the Weather Envoy!
The Davis Instruments’ Weather Envoy
®
provides a way of getting weather data
from your Vantage Pro2
™
or Vantage Vue
weather station into your Windows XP,
Vista, or 7; or Macintosh (OS X) computer
using our WeatherLink
®
software.
The Weather Envoy includes the data
collection and logging functions of the
Vantage consoles, but in a smaller package
that can be placed next to your computer, or
in a field installation. It can be used to free your wireless console from the
need to be near the computer, or it can be used in place of either a wired or
cabled console. Both cabled and wireless versions are available. Used with our
WeatherLink software and data logger, the Weather Envoy allows you to view,
store, plot, analyze, export, share, and print your weather data.
Contents
Before continuing, please be sure your Weather Envoy package includes the
following:
• Weather Envoy
• Two #6 x 1'' screws for wall mounting
• AC-power adapter
Required for Operation
You will also need the following Davis weather products to use your Envoy:
All Weather Envoys:
• Any version of WeatherLink for Vantage Pro2 and Vantage Vue, Windows
version 5.2 or later (#6510USB, 6510SER, 6540, 6544, 6550, 6555, 6560),
Mac OS X version 5.01 or later (#6520)
Wireless Weather Envoy:
• Wireless Vantage Pro2, Vantage Pro2 Plus, or Vantage Vue weather station
(#6152, 6153, 6162, 6163, 6250) or just the wireless ISS (#6322, 6323,
6327, 6328, 6357)
Cabled Weather Envoy:
• Cabled Vantage Pro2 or Vantage Pro2 Plus weather station ISS (#6322C
and 6327C; included with 6252C, 6162C)

DAVIS Vantage Vue Specifications

General

Wind Speed Range	2 to 150 mph (3 to 241 km/h)
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Collector Type	Tipping bucket
Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Wireless Transmission Range	up to 1000 ft (300 m)
Humidity Range	1 to 100% RH
Wind Direction	0 to 360°
Wind Direction Accuracy	±3°
Power Supply	Solar-powered with battery backup
Console Display	LCD with backlight
Power (Console)	3 C batteries or AC adapter
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Solar Radiation Sensor	Not included
UV Sensor	Not included
Rain Measurement Accuracy	±4% at rates up to 2 in (50 mm) per hour
