DAVIS Vantage Vue Manual

Install the Data Logger
4
3. Carefully insert the data logger (Serial, USB or IP) into the connector slot,
making sure to push the data logger firmly into place.
Inserting the Serial, USB or IP data logger into the Envoy
4. Rejoin the case halves, making sure the data logger cable passes through the
cable channel.
5. Fasten using the three screws you removed in step 1.
Data Logger
Cable Channel
Serial
Data Logger
Data Logger
Cable Channel
USB
Data Logger
Data Logger
Cable Channel
WeatherLinkIP
Data Logger

DAVIS Vantage Vue Specifications

General

Wind Speed Range	2 to 150 mph (3 to 241 km/h)
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Collector Type	Tipping bucket
Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Wireless Transmission Range	up to 1000 ft (300 m)
Humidity Range	1 to 100% RH
Wind Direction	0 to 360°
Wind Direction Accuracy	±3°
Power Supply	Solar-powered with battery backup
Console Display	LCD with backlight
Power (Console)	3 C batteries or AC adapter
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Solar Radiation Sensor	Not included
UV Sensor	Not included
Rain Measurement Accuracy	±4% at rates up to 2 in (50 mm) per hour
