Daymak MAX User Manual

18
Seat
The Tono X 36V comes with a quick release latch that allows you to easily adjust
the height of the seat. It also comes with an optional back rest for additional support
To adjust the seat height take the lever see below)at pry it away from the seat post.
This will loosen the seat and allow you to move it up or down until it is at the
desired height.
Once it has been adjusted. Clamp the lever back down to secure it.
Tires
On each re you will nd a valve with a cap as seen here. Unscrew the cap and ll the res
with a pump between 50 and 85 PSI

Daymak MAX Specifications

General

Category	Electric Scooter
Motor Power	500W
Battery Type	Lithium-Ion
Battery Voltage	48V
Battery Capacity	12Ah
Max Speed	32 km/h
Weight Capacity	120 kg
Brakes	Disc Brakes
Tire Size	10 inches
Charging Time	4-6 hours
Range	40 km
Weight	23 kg
