Daymak MAX User Manual

29
Specifications
Name Tono X
Motor 350W
Voltage 36V
Amp Hour 7.8AH
Watt Hours 281WH
Battery Life 1000 cycles
Battery Lithium Ion
Removable Battery No
Charger 42V 2.0A
Charge Time 2 - 4 Hours
Lights LED
Max Load 275 lbs.
Assembled Weight 43 lbs.
Assembled Length 6
Assembled Width 23"
Assembled Height 41"
Seat Height 37"
Seat Width 6"
Seat Length 10"
Boxed Weight 59 lbs.
Boxed Length 72
Boxed Width 9
Box Height 37
Range Up to 40 km
Speed 32 km/h
Climbing Incline 20 degrees
Front Wheel 700 x 32C
Rear Wheel 700 x 32C
Gauges Battery Level / Odometer / Speedome-
ter
Ground Clearance 8"
Wheel Base 45"
Battery Weight 3 lbs

Daymak MAX Specifications

General

Category	Electric Scooter
Motor Power	500W
Battery Type	Lithium-Ion
Battery Voltage	48V
Battery Capacity	12Ah
Max Speed	32 km/h
Weight Capacity	120 kg
Brakes	Disc Brakes
Tire Size	10 inches
Charging Time	4-6 hours
Range	40 km
Weight	23 kg
