Important Safety Instructions
To reduce the risk of electric shock, do not remove cover. No user
serviceable parts inside. Refer servicing to qualied personnel. To
reduce the risk of re and shock do not expose unit to rain or moisture.
The unit should be connected to an earth grounded AC electrical
socket. The unit should be operated in a well ventilated area. Minimum
clearance is 2 inches from the ventilation openings.
Dayton Audio
®
Last Revised: 1/12/2021
daytonaudio.com
tel + 937.743.8248
info@daytonaudio.com
705 Pleasant Valley Dr.
Springboro, OH 45066
USA
5-Year Limited Warranty
See daytonaudio.com for details
Specifications:
Power Output: 25 watts RMS x 2 into 4 ohms
Minimum Speaker Impedance: 4 ohm
Frequency Response: 20-20,000 Hz, ±2 dB
Channel Separation: 80 dB
Dynamic Range: >83 dB
Signal-to-Noise Ratio: >85 dB
Preamplifier Tubes: 6K4 x 2, 6UI x 2
Headphone Amp Output: 30 mW @ 600 ohms; 20 mW @ 300 ohms;
15 mW @ 32 ohms; 10 mW @ 16 ohms
(maximum @ 1 kHz, <1% THD+N)
Bluetooth Version: 5.0
Input Impedance: 47k ohms (minimum)
Input Sensitivity: 500 mV
Dimensions: 6.3" H x 7.5" W x 9.2" D
Weight: 6.6 lbs
