3KP64 - 4.2
3000PLUS WITH 5D64 INSTRUCTION MANUAL V. SB.2
Daytronic Corporation
2211 Arbor Blvd. Dayton, OH 45439 • (800) 668-4745
Tel: (937) 293-2566 • Fax: (937) 293-2586 • www.daytronic.com
4. SOFTWARE CONFIGURATION
AND CALIBRATION
GETTING CONFIGURATOR HELP
The Configurator provides a complete ON-LINE HELP
system. To open HELP—and for instructions on how to
use the
F1 key to get context-sensitive help for a Con-
figurator page, field, or button—select
Configurator
HELP...
from the Configurator’s Help menu. Click the
OPEN CONFIGURATOR HELP button (or press [Alt]
h
). The introductory topic entitled “What is the
3000PLUS Configurator?” will appear. For the complete
HELP
Contents or Index, click the respective tab.
Be sure to study the following “Getting Started” HELP
topics—along with Sections 4.B through 4.E of this man-
ual—before proceeding:
•
Setup and Testing of Serial Communications
• Read Me (Version x.x)
You may also
• upload the current configuration of the connected
3000PLUS instrument to a new configuration file for
storage and/or editing
• view/print a configuration report or save it as a “.txt”
file
STARTING THE 3KP CONFIGURATOR
Instructions for installing and running the Configurator
software were given in Section 1.F.
After the Configurator starts up, you can do one of sev-
eral things:
• OPEN AN EXISTING 3000PLUS CONFIGURATION
by selecting
Open... from the File menu (a SAM-
PLE CONFIGURATION is installed with the Configu-
rator software, to let you see typical setup entries)
• CREATE A NEW 3000PLUS CONFIGURATION by
selecting
New... from the File menu
• CREATE A NEW 3000PLUS CONFIGURATION by
uploading the setup data contained in the connect-
ed 3000PLUS instrument, by selecting
Upload
Configuration from 3000PLUS...
from the Config-
uration
menu
• VIEW AND/OR MODIFY THE “LIVE” OUTPUT AND
PRESENT CONFIGURATION of the connected
3000PLUS instrument by going to the
Calibrate /
Configure
page and pressing the View / Set . . .
button
• SEND ONE OR MORE COMMANDS to the connect-
ed 3000PLUS instrument by selecting
Send Com-
mand...
from the Communications menu
An overview of the procedure for creating a new instru-
ment configuration “off-line” via the
New... command is
given in Section 4.C, below. For on-line modification of
the connected 3000PLUS instrument’s configuration,
see Section 4.D.
