3KP64 - 4.3
3000PLUS WITH 5D64 INSTRUCTION MANUAL V. SB.2
Daytronic Corporation
2211 Arbor Blvd. Dayton, OH 45439 • (800) 668-4745
Tel: (937) 293-2566 • Fax: (937) 293-2586 • www.daytronic.com
FILE MENU
1
N
ew... ( = [Control]N)
Select to create a new configuration
O
pen... ( = [Control]O)
Select to open an existing configuration
C
lose
2
Select to close the open configuration
Save A
s...
2
( = [Control]S)
Select to save the open configuration using a
new file name
Exit
Select to exit the Configurator program
COMMUNICATIONS MENU
1
C
omm’s Setup and Test…
Select to set up and test serial communications
with the connected 3000PLUS
Send Command… ( = [Control]T)
Select to send one or more mnemonic com-
mands to the connected 3000PLUS
CONFIGURATION MENU
1
V
alidate Configuration
2
Select to validate the open configuration
D
ownload Configuration to 3000PLUS…
2
Select to download the open configuration to the
connected 3000PLUS
Upload Configuration from 3000PLUS…
Select to upload the current setup values of the
connected 3000PLUS to a new configuration
REPORTS MENU
2
Full Configuration Report
1
Select to view/print the full configuration
Configuration Commands List
1
Select to view/print the set of mnemonic com-
mands representing the open configuration
Close Report Preview
3
( = [Control]W)
Select to close the presently displayed report
preview
Zoom
3
Select to switch between the selected Zoom
Magnification Percentage
and the best window
“fit” of the displayed report preview
[Zoom Magnification Percentage]
3
Select the magnification percentage to be
applied to the displayed report preview
Output to Notepad
3
Select to output the displayed report to a “.txt” file
Page Setup…
3
Select to open the standard Windows PAGE
SETUP window
Print...
3
( = [Control]P)
Select to open the standard Windows PRINT win-
dow
HELP MENU
Configurator HELP...
Select to open the Configurator’s HELP system
and for an explanation of how to use the
F1 key
to get context-sensitive help for a Configurator
page, field, or button
About...
Select to display Configurator version, copyright,
and protection information
4.B SUMMARY OF CONFIGURATOR MENUS
4. SOFTWARE CONFIGURATION
AND CALIBRATION
1
Not active when a REPORT preview is being displayed.
2
Not active when a configuration has not yet been opened.
3
Only active when a REPORT preview is being displayed.
