MP1=$ $ = Configuration Description (first 16
characters)
NOTE: The MP1, MP2, and/or MP3
string may be NULL (no characters), if
desired.
MP2=$ $ = Configuration Description (next 16
characters)
MP3=$ $ = Configuration Description (final 16
characters)
MP4=$ $ = Last Download Date/Time
NOTE: The 3KP Configurator software
requires an MP4 format of
“(M)M/(D)D/YY (H)H:MM A” or
“(M)M/(D)D/YY (H)H:MM P,” depending
on whether the time is “AM” or “PM,”
respectively; digits in parentheses are
optional
MP5=$ $ = Engineering Units
NOTE: The MP5 string may be NULL
(no characters), if desired.
MP8=$ $ = Last Calibration Date/Time
NOTE: The 3KP Configurator software
requires an MP8 format of
“(M)M/(D)D/YY (H)H:MM A” or
“(M)M/(D)D/YY (H)H:MM P,” depending
on whether the time is “AM” or “PM,”
respectively; digits in parentheses are
optional
MP9=$ $ = Transducer Model/Serial Number
NOTE: The MP9 string may be NULL
(no characters), if desired.
MP1 Reads the current MP1 string; returns $
MP2 Reads the current MP2 string; returns $
Etc.
MSF MODULE SCALE FACTOR
MSF=m Sets the installed 5D64’s gain (scale
factor) to the value m, where 1.0000 ≤
m ≤ 1.5999 (for the Model 5D64); m is
used as a multiplier for the full-scale
input range (see
RNG, below).
MSF Reads the current module scale factor
value; returns m in the format 1.XXXX.
RNG RANGE
RNG=r Sets the installed 5D64’s range code to
the alphanumeric character r. Allowed
full-scale input ranges are module-spe-
cific; for the Model 5D64, they are as
follows (see Table 2, Appendix B, for
the associated “practical” ranges):
r = 0 : 0.05 VDC r = D : 4 VDC
r = 1 : 0.075 VDC r = E : 5 VDC
r = 2 : 0.1 VDC r = F : 7.5 VDC
r = 3 : 0.15 VDC r = G : 10 VDC
r = 4 : 0.2 VDC r = H : 15 VDC
r = 5 : 0.3 VDC r = I : 20 VDC
r = 6 : 0.4 VDC r = J : 30 VDC
r = 7 : 0.5 VDC r = K : 40 VDC
r = 8 : 0.75 VDC r = L : 50 VDC
r = 9 : 1 VDC r = M : 75 VDC
r = A : 1.5 VDC r = N : 100 VDC
r = B : 2 VDC r = O : 150 VDC
r = C : 3 VDC
RNG Reads current module range code;
returns r.
SYM NEGATIVE SYMMETRY
SYM=m Sets the installed 5D64’s negative sym-
metry adjustment to the value m (% of
full scale), where –2 ≤ m ≤ 2.
SYM Reads current negative symmetry
adjustment value; returns m in the for-
mat X.XX.
APPENDIX A: MNEMONIC COMMANDS
