HPT PEAK “DEFEAT” THRESHOLD*
HPT=t Sets the width of the “peak defeat”
input threshold for the meter’s “auxil-
iary” DAC output (Channel 2) to t, which
is expressed in engineering units and
to the decimal-point precision of the
current
FSU value; -199990 ≤ h ≤
199990; t should not be greater than
20% of the current full-scale reading.
HPT Reads current peak defeat threshold;
returns t.
IP0 through IP2 INSTRUMENT PARAMETER
Used to write and read miscellaneous instrument
configuration information, as follows (each
IPn string
$ can have up to 16 ASCII characters). Analogous to
the set of
MODULE PARAMETER (“MP”) com-
mands, above. NOTE: THESE COMMANDS ARE NOT
PRESENTLY USED BY THE 3KP CONFIGURATOR.
LAT LIMIT LATCH
LAT=ON Enables latching of both limits for the
meter’s “auxiliary” DAC output (Chan-
nel 2) by setting the latch mode to ON.
LAT=OFF Disables latching of both limits for the
meter’s “auxiliary” DAC output (Chan-
nel 2) by setting the latch mode to ON.
LAT Reads current latch mode setting;
returns ON or OFF.
LIM LIMITS
LIM=ON Enables continuous monitoring of both
limits for the meter’s “auxiliary” DAC
output (Channel 2) by setting the limit
mode to ON.
LIM=OFF Disables continuous monitoring of both
limits for the meter’s “auxiliary” DAC
output (Channel 2) by setting the limit
mode to OFF.
LIM Reads current limit mode setting;
returns ON or OFF.
LHY LOW LIMIT HYSTERESIS
LHY=h Sets the width of the low-limit hystere-
sis deadband for the meter’s “auxiliary”
DAC output (Channel 2) to the value h,
which is expressed in engineering units
and to the decimal-point precision of
the current
FSU value; 0 ≤ h ≤ 199990;
h cannot be greater than the difference
between the existing
HIL and LOL val-
ues.
LHY Reads current low-limit hysteresis
value; returns h.
LKR LEAK RATE
LKR=m Sets the decay rate for the meter’s
“auxiliary” DAC output (Channel 2) to m
(% of full scale per second), where
-3.50 ≤ m ≤ 3.50.
LKR Reads current leak rate value; returns
m.
LMS LIMITS SECURITY
LMS=ON Turns on the instrument’s limits securi-
ty, so that the local operator can view
and modify limit values only through
the standard front-panel setup proce-
dure.
LMS=OFF Turns off the instrument’s limits securi-
ty, so that the local operator can use
the front-panel buttons to view and
modify limit values during normal run-
time operation (without entering setup
mode).
LMS Reads current limits security setting;
returns ON or OFF.
LOL LOW LIMIT
LOL=h Sets the low-limit setpoint for the
meter’s “auxiliary” DAC output (Chan-
nel 2) to the value h, which is
expressed in engineering units and to
the decimal-point precision of the cur-
rent
FSU value; -199990 ≤ h ≤ 199990;
h cannot be greater than the existing
HIL value. Applies only to the meter’s
“auxiliary” DAC output (Channel 2).
LOL Reads current low-limit setpoint value;
returns h.
PKM PEAK MODE
PKM=n Sets to n the peak mode to be in effect
for the meter’s “auxiliary” DAC output
(Channel 2) when peak capture opera-
tion is enabled via logic-signal input; n =
1 (for PEAK mode) or 2 (for VALLEY
mode).
PKM Reads current peak mode setting;
returns n.
APPENDIX A: MNEMONIC COMMANDS
* Formerly called “HAVE PEAK THRESHOLD.”
