Raider Max 175 (single-seat, double-seat): Service Manual EEC Version:2.0 April 2005
11
Inspection and Cleaning of Filters
z Paper Filter
a) Remove the filter from its housing;
b) Lightly tap the filter on an object to knock out the dust;
c) Replace the filter element if it is wrinkled or torn.
z Foam Filter
a) Remove the filter out of its steel cage;
b) Wash the filter in non-flammable cleaning solvent;
c) Submerge the filter in oil and squeeze it to remove excess oil;
d) Install the filter element back into the air box.
2.3.5 Nuts and Bolts in Chassis
Inspect the nuts and bolts in the chassis during the first week and every month thereafter.
The nuts and bolts become loose normally after use, please check for the looseness regularly.
2.3.6 Tightening Torque Table
Conventional Marked Bolt 8.8 Marked Bolt Bolt Diameter
(mm)
N•m Kg•m lb-ft N•m Kg•m lb-ft
4 1-2 0.1-0.2 0.7-1.5 1.5-3 0.15-0.3 1.0-2.0
5 1-4 0.2-0.4 1.5-3.0 3-6 0.3-0.6 2.0-4.5
6 4-7 0.4-0.7 3.0-5.0 8-12 0.8-1.2 6.0-8.5
8 10-16 1.0-1.6 7.0-11.5 18-28 1.8-2.8 13.0-20.0
10 22-35 2.2-3.5 16.0-25.5 40-60 4.0-6.0 29.0-43.5
12 35-55 3.5-5.5 25.5-40.0 70-100 7.0-10.0 50.5-72.5
14 50-80 5.0-8.0 36.5-58.0 110-160 11.0-16.0 79.5-115.5
16 80-130 8.0-13.0 58.0-94.0 170-250 17.0-25.0 123.0-181.0
18 130-190 13.0-19.0 94.0-137.5 200-280 20.0-28.0 144.5-202.5
2.3.7 Fuel Switch Inspection
a) Stop the engine, remove the gasoline tube from the carburetor, and check if the gasoline is
flowing;
z Before and during the cleaning, inspect the element for tears; replace it if it’s torn.
z Make sure that the element is seated properly and no foreign material can pass by it
