Dazon Raider Max 175S - Drive Pulley, Clutch & Driven Pulley

Raider Max 175 (single-seat, double-seat): Service Manual EEC Version:2.0 April 2005
20
3.3 Drive Pulley, Clutch & Driven Pulley
3.3.1 Disassembly Diagram
1.Crankecase, Right 2.Driven Pulley Comp.
3.Belt 4. Drive Pulley Comp.
5.Gasket, Left Crankcase 6. Crankcase, Left
7.Special Screw Set 8.Shroud (Left Crankcase Cover)
5
1
2
34
