DB ELETTRONICA TELECOMUNICAZIONI S.p.A.
PM 1000 – 1 kW FM Broadcasting Transmitter - USER’S MANUAL
48 /101
Fig. 6.3 - VCO STAGE ELECTRICAL SCHEMATIC
