dbx 1066 - Technical Specifications - Part 1; Input;Output Specifications; Sidechain Interface Specifications

Inputs / Entrées / Eingänge / Entradas
Connectors: Female XLR and 1/4" TRS (Pin 2 and tip hot)
Connecteurs: XLR femelles et jacks stéréo 6,35 (point chaud = borne 2 et pointe)
Anschlüsse: XLR-Buchsen weibl. und 6,3-mm-Stereoklinkenbuchsen (Inphase = Stift 2 bzw. Spitze)
Conectores: Hembra de XLR y jack estéreo 6,3 mm (espiga 2 y punta = en fase)
Type: Electronically balanced/unbalanced, RF filtered
Type : Symétrie, asymétrie électroniques, filtrées contre les interférences radio
Schaltung: Elektronisch symmetriert/asymmetrisch, HF-geschützt
Tipo: Electrónicamente balanceado/desbalanceado, con filtro RF
Impedance: Balanced > 50 kΩ, unbalanced >25 kΩ
Max Input Level: > +24 dBu balanced or unbalanced
CMRR: 40 dB; Typically >55 dB at 1 kHz
Outputs / Sorties / Ausgänge / Salidas
Connectors: Male XLR and 1/4" TRS (Pin 2 and tip hot)
Connecteurs: XLR mâles et jacks stéréo 6,35 mm (point chaud = broche 2 et pointe)
Anschlüsse: 6,3-mm-Stereoklinkenbuchsen, XLR-Buchsen männl. (Inphase = Stift 2 bzw. Spitze)
Conectores: Clavijas jack estéreo 6,3 mm, XLR macho (espiga 2 y punta = en fase)
Type: Servo-balanced/unbalanced, RF filtered
Type: Symétrique, asymétrique, filtrées contre les interférences radio
Schaltung: Servosymmetriert/asymmetrisch, HF-geschützt
Tipo: Balanceado/desbalanceado, con filtro RF
Impedance: Balanced 120Ω, unbalanced 60Ω
Max Output Level: > +21 dBu, >+20 dBm (600Ω) balanced/unbalanced
Sidechain Input / Entrée Sidechain / Sidechain-Eingang / Entrada Sidechain
Connector: 1/4” TS
Connecteur: jack mono 6,35 mm
Anschluss: 6,3-mm-Monoklinkenbuchse
Conector: Clavija jack mono 6,3 mm
Type: Unbalanced, RF filtered
Type: Asymétrique, filtrée contre les interférences radio
Schaltung: Asymmetrisch, HF-geschützt
Tipo: Desbalanceado, con filtro RF
Impedance: > 10 kOhm
Max Input Level: > +24 dBu
Sidechain Output / Sortie Sidechain / Sidechain-Ausgang / Salida Sidechain
Connector: 1/4” TRS (tip hot)
Connecteur: Jack stéréo 6,35 mm (point chaud = pointe)
Anschluss: 6,3-mm-Stereoklinkenbuchse (Inphase = Spitze)
Conector: Clavija jack estéreo 6,3 mm (punta = en fase)
Type: Impedance balanced, RF filtered
Type: Impédance symétrique, filtre RF
Schaltung: Impedanzsymmetriert, HF-geschützt
Tipo: Balanceado, con filtro RF
Impedance: Balanced 2 kOhm, unbalanced 1 kOhm
Max Output Level: > +21 dBu balanced or unbalanced
System Performance/ Caractéristiques système / Audiodaten / Datos audio
Bandwidth: 20 Hz to 20 kHz, +0/-0.5 dB
Frequency Response: 0.35 Hz to 200 kHz, +0/-3 dB
Noise: < -95 dBu, unweighted, 22 kHz measurement bandwidth
Dynamic Range: > 120 dB, unweighted
THD+Noise: 0.008% typical at +4 dBu, 1 kHz unity gain
0.0496% typical at +20 dBu, 1 kHz, unity gain
< 0.1% any amount of compression up to 40 dB, 1 kHz
IMD: < 0.1% SMPTE
Interchannel Crosstalk: < -100 dB, 20 Hz to 20 kHz
VCA: dbx V2™
Stereo Coupling: True RMS Power Summing
Specifications / Spécifications techniques
Technische Daten / Especificaciones
®
65
SPECIFICATIONS
