2. Press the INPUT A button and the EQ 1 button to move to the Input Graphic EQ.
3. Turn Encoder knob #3 to link the Graphic EQs on Inputs 1 and 2.
4. Press the INSERT 2 button and turn the Encoder #1 knob to select the Compressor.
5. Turn Encoder knob #3 to link the Compressors on Inputs 1 and 2.
6. Select the Input Router on Input A by pressing the MIX/ROUTE button and INPUT A button.
In Use
Section 5
33
