Specifications ( 480R Remote Controller DriveRack™)
Inputs
Number of Inputs: 1 Real Time Audio Analyzer
Connectors: Female XLR
Type: Electronically balanced/RF filtered
Impedance: >40kΩ
Max input RTA Level: -10 dBu
CMRR: >40 dB typical, >55 dB at 1kHz
Input Gain Range RTA: 10 dB to 70 dB w/60 dB typical
Miscellaneous
Network: Proprietary RS-485 link
GUI: RS-232 interface for computer display and
RTA Microphone: Optional
ROM Upgrade: Flash upgradeable through RS-232
Dimensions
Dimensions: Height- 12.24” X Width- 19” X Depth 3.20”
Specifications ( 480P Power Supply)
Inputs
Connectors: RS 232 and RS 485 Network Communication Connectors
Dimensions
Dimensions: Height- 1.75” X Width- 19” X Depth 7.90”
