dbx PX - Two Mains, One Subwoofer Setup

6.2 Two Mains/One Subwoofer Setup
Hardware
Make sure that the mixer and powered speakers are turned off prior to powering up the
DriveRack® PX.
Connect the outputs from the mixer to the inputs of the DriveRack® PX.
Connect the main outputs of the DriveRack® PX to the main powered speakers.
Connect the Left/Mono sub output of the DriveRack® PX to the sub powered speaker.
Software
Use the Wizard to set up a specific preset. Press and hold the <SETUP> button to begin.
See page 8 for more information.
