De Nora Capital Controls 71V3B Series - Component Description

115.6031.0 - 8 -
1.2 Model Number Breakdown
Refer to the De Nora Water Technologies data sheet for the model number of the equipment furnished.
Model Number Breakdown
Model No. 71V3B ___ ___ ___ ___ ___
Gas & Capacity
01 - Chlorine 12000 lb/day (227 kg/h)
02 - Chlorine 8000 lb/day (160 kg/h)
03 - Chlorine 6000 lb/day (120 kg/h)
11 - Sulfur Dioxide 75000 lb/day (150 kg/h)
12 - Sulfur Dioxide 5900 lb/day (115 kg/h)
13 - Sulfur Dioxide 4500 lb/day (90 kg/h)
21 - Ammonia 2500 lb/day (50 kg/h)
22 - Ammonia 2000 lb/day (40 kg/h)
23 - Ammonia 1500 lb/day (30 kg/h)
Control Voltage
01 - 120 Vac
02 - 220/240 Vac
Heater Voltage/Magnetic Contactor
A0-UW - Voltage/Phase/Mounting/Nema Rating
XX - Contactor supplied by Others
Water Level Control Switch
01 - Required
02 - Not Required
Documentation
XX - Not Required
01- Certication Documents
