ERUDECORP.RAP
PROGRAMMING PROCEDURES
Positioning of operator 1
Positioning of operator 2
Memorization of the motors’ stroke
Deletion of transmitters
Transmitters memorizing
Search and deletion of a transmitter
Restoring the operating parameters
Lock access to programming
How to learn connected DE@NET devices (unused at the moment)
Restoring the “I/O” con gurations (input/output)
Downloading data on the external memory unit
Uploading data from an external memory unit
Visualisation of inputs and operations-counter status
Unused parameter
Unused parameter
.RAP
INPUTS CONFIGURATION PARAMETERS
INPUT_3 selectioning input type
INPUT_1 operating selection
INPUT_2 operating selection
INPUT_3 operating selection
INPUT_4 operating selection
INPUT_5 operating selection
INPUT_6 operating selection
SETTABLE VALUES
SETTABLE VALUES
DEFAULT VALUES
(for different standards of installation)
TYPE
00
TYPE
01
TYPE
02
TYPE
03
• 000: IN3 type=free contact
• 001: IN3 type=constant resistance 8K2
• 000: NONE (unused parameter)
• 001: START (start)
• 002: PED. (pedestrian)
• 003: OPEN (separated open)
• 004: CLOSE (separated close)
• 005: OPEN_PM (man present open)
• 006: CLOSE_PM (man present close)
• 007: ELOCK-IN (electric-lock activation. See P062)
• 008: PHOTO 1 (photocell 1)
• 009: PHOTO 2 (photocell 2)
• 010: SAFETY 1 (safety rib 1)
• 011: STOP (lock) / SAS INPUT (with NET_EXP only)
• 012: FCA1 (opening limit switches Mot1)
• 013: FCA2 (opening limit switchtes Mot2)
• 014: FCC1 (closing limit switches Mot1)
• 015: FCC2 (closing limit switches Mot2)
• 016: SAFETY 2 (safety rib 2)
• 017: OPEN_INT (with NET_EXP only)
• 018: OPEN_EXT (with NET_EXP only)
• 019: AUX_IN (with NET_EXP only)
• 020: SAFETY INHIBITION (SAFETY inhibition)
IN1
IN2
IN3
IN4
IN5
IN6
