INSTALLATION INSTRUCTIONS
14. DIMENSIONI CALDAIA 15. DIMENSIONS OF BOILER
Figure 5
24 FF - 24 MI FF 24 - 24 MI
CG_2009 / 1006_1802
CG_2009 / 1006_1803
G”3/4 HEATING FLOW G”1/2 DOMESTIC HOT WATER OUTLET
G”3/4 HEATING RETURN G”1/2 DOMESTIC COLD WATER INLET
G”3/4 GAS INLET TO BOILER G”3/4 STORAGE BOILER COIL FLOW
WARNING
Tighten the boiler nipple water connections with care (maximum tightening torque 30 Nm).
Figure 4
24 MI - 24 MI FF 24 - 24 FF
CG_2263 / 1007_1403
