DLED4 Series • Light Head and Power Supply • Instruction Manual • V1.1
14
Dimensions
DT4
DT4-BI
DT4-DMX
DT4-BI-DMX
DT4-BAT
DT4-BI-BAT
2,83" (72 mm) 50 mm (1,98")
5,63" (143 mm)
2,83" (72 mm) 1,98" (50 mm)
4,45" (113 mm)
2,83" (72 mm) 1,98" (50 mm)
10,35" (263 mm)
2,83" (72 mm)
1,98" (50 mm)
10,35" (263 mm)
2,83" (72 mm) 1,98" (50 mm)
8,39" (213 mm)
DT4 DT4-BI
DT4-DMX
DT4-BAT-AB / DT4-BAT-XLR
DT4-BI-BAT-AB/DT4-BI-BAT-XLR
DT4-BI
Technical Specifications
Input AC 90-264 V / 50 VA / 0,2-0,21 A / 47 W
Input DC (Battery Version) 10,2-18 V / 50 VA / 4,6-2,6 A / 47 W
Output 48 V / 40 W
Dimming 100 - 5 %
Protection Class IP 40 , Protection Class 1
Cable Length AC 2,5 m / DC 1,4 m XLR 5 pin
Weight 1000 g (DT4-E); 1300 g (DT4-BI-DMX-E)
Mesurements see drawings
