DLED4 Series • Light Head and Power Supply • Instruction Manual • V1.1
16
A
Tripod adapter for stands with
16 mm (5/8“) studs
B
Swiveling Light Head Yoke
C
Swiveling latch to hold front-end
accessories.
D
3 fixed holders / receptacles
for front-end accessories, like
barn door, imager / projection
attachment, filters and light
shield ring.
E
Focus Ring
F
Handle
G
Heat Sink (do not cover)
H
XLR input from power supply
K
I
L
M
J
I
Brightness controls [DIM]
I
Control LED‘s
K
Cable to light head [DLED4-T/D, DLED4-BI]
L
Hanging loop for mounting on tripod
M
Color controls [Bicolor version only]
N
Fuse holder
O
Power cord
P
Power switch
H
C
F
A
B
P
E
G
4 Operating elements
Electronic Transformer DT
N
O
Light Head
D
