DLED4 Series • Light Head and Power Supply • Instruction Manual • V1.1
3 Technical specifications and dimensions
Dimensions
DLED4-D / DLED4-T / DLED4-BI
4,3" (109 mm)
7.2" (183 mm)
6.38" (162 mm)
7,91" (201 mm)
Flood Spot
Technical Specifications
Input DC 48 V / 40 VA / 1 A / 40 W
Dimming 100 - 0 %
Classification IP 20 , Protection Class 3
Connection XLR 5 Pin
Weight 1300 g
Mesurements see drawings
Focus 60-4° (1:20)
Focus Kontrolle 1 turn of the ring
UV no UV radiation
Operating Position any
Cooling passive cooling – no fan – no noise
Accessory holder 76 mm diameter
Stand Fitting 5/8 inch, 16 mm baby receptacle for baby stud
Optionally usable as 28 mm stud when screw / button is removed.
inside: 16 mm ; outside: 28 mm (when holding screw removed)
