1 General
PLEASE NOTE!!!
The dedolight LED lighting system (DLED) is an instrument for professional use. Please read this manual carefully.
During operation the luminaire (light head) may become hot (about 90°C). These areas are marked with stickers.
Avoid long-term contact with these areas of the housing. Ensure adequate ventilation of the light head and keep a
minimum distance of 0.5m from combustible materials.
Switch the system off and unplug the AC cable before making electrical connections.
The ballast DT4 is an independent electronic control-gear for the light head DLED4. In AC versions of DT4 the
primary coils of the impulse transformer are directly connected to the mains power supply. The ballast DT4 pro-
vides Safe Extra Low Voltage (SELV). The ballast DT4 is limited power supply (LPS) type with constant current/
constant voltage output. In the light head DLED4 the voltages used are below 50V. There are no high frequencies
or electro-magnetic interferences during operation. These devices are made according to universal low-voltage
directives. A CE certificate is to be found at the end of this manual.
Electrical and electronic repairs, as well as replacement of the LED module, should be performed exclusively by
Dedo Weigert Film GmbH or an authorized representative, or a qualified and trained electrician.
1.1 Explanation of Symbols
In this manual safety Notes are marked by symbols. Each of these safety Notes is introduced by words, clarifying
the degree of hazard. In order to avoid accidents, personal injuries and property damage, these safety instruc-
tions are to be complied with prudently and carefully.
DANGER! ... Indicates a directly hazardous situation which may lead to death or serious injury if not
avoided.
WARNING! ... Indicates a potentially Dangerous situation which could lead to death or serious injury if
not avoided.
CAUTION! ... Indicates a potentially hazardous situation which could lead to minor injury if not avoided.
NOTE! ... Indicates a potentially Dangerous situation which could result in material and in environmen-
tal damage.
Recommendations ... this symbol highlights useful tips and recommendations for efficient and fault-
free operation.
