DEERE JDLink - Customer Owned SIM Card; Satellite Module Operation; Satellite Alert Message Handling

PROOFPROOF
SystemOverview
AE77568,000020C-19-28JUN16-1/1
AE77568,00001F0-19-28JUN16-1/1
CustomerOwnedSIM
MTGcontainsslotforamicroSubscriberIdentityModule
(SIM)cardforuseincountrieswherecustomersprovide
theirownSIMcard.T oinsertmicroSIMcard:
NOTE:TurnkeyswitchOffbeforeinsertingor
changingSIMcard.
1.Removecapscrews(A)andSIMinsert(B).
2.InsertmicroSIMcard(C)intoslot(D)asillustrated.
3.Reinstallinsertandcapscrews.
A—CapScrew(2used)
B—SIMInsert
C—MicroSIMCard
D—MicroSIMCardSlot
PC22044—UN—20JAN16PC22025—UN—20JAN16
SatelliteModuleTheoryofOperation
Inselectregions,anoptionalsatellitemoduleisoffered
thatisacompaniontothemodulartelematicsgateway
(MTG).JDLink™satellitemodulehardwarelookslike
MTGhardware,butcontainsasatellitemodem.Satellite
modemallowsMTGtotransferdatatoandfromJDLink™
hostserveroverasatelliteconnectionwhenavalid
cellularorwirelessnetworkisunavailable.
AftersatellitemoduleisinstalledwithMTG,satellite
servicemustbeactivatedforsatellitemoduleto
communicateoversatellitenetwork.
SatelliteCommunication
Scheduledcallfrequencydefaultstoonecallperday
whenusingsatellitemodule.Thisfrequencycanbe
changedtoonetimeperweekonwebsite.
AslongasMTGhascellularcoverage,satellitemoduleis
notused.TheMTGattemptstocallusinglastsuccessful
method(cellularorsatellitesignal).Ifmachinemoves
intoanareaofweakornocellularcoverage,MTG
cannotcompleteacall.JDLink™websiteshowsthat
machinemissedacall.Onehourafterthefailedcall,
MTGescalatescalltosatellitemodule.
IfMTGissetforadailycallin,completesacall,andmoves
outofcellularcoveragewithnoredalertsorimmediate
callsrequired,thenextcallattemptisin24hours.Itcan
take25hrbeforemessageisreceivedorsenttomachine.
Callsoversatellitesignalaremarkedwithasatelliteicon
onJDLink™website.Machinemusthaveaclearviewof
theskytoconnecttosatellitenetwork.
AlertMessageswithSatellite
Alltelematicsmessageshavearoutingclassandpriority
thatdeterminewhethertheyaresentimmediatelyorwith
thenextcallattempt.Thereisspeciallogictodetermine
whethermessagesaresentusingMTGorsatellitemodule
ifinitialcellularcallfailed.
•
Redalertsaresentimmediately.
•
YellowandInformationalalertsareatleast2hrold
beforebeingsentwiththenextscheduledcall,orwitha
website-initiatedcallorrequesttomachine.
•
Securityalerts,suchasgeofenceandcurfew,depend
onuser-definedwebsitesettings.
•
Requestssentfromwebsitetomachineareretrieved
withinabout5minutes.Ifrequestwasthefirst
communicationwithamachineafterleavinganareaof
cellularcoverage,requestscantakeupto1hour.
Somelimitationsexistwhenusingsatellitemodule.
Applicationsthatrequireanuninterruptedcellular
connectionarenotsupported.Forexample,Service
ADVISOR™Remote,JohnDeereRemoteDisplay
Access,JohnDeereWirelessDataTransfer,andJohn
DeereMachineSyncshareddataarenotsupporteddue
tothesatelliteconnection’slimitedcapacityandlatency.
JDLinkisatrademarkofDeere&Company
ServiceADVISORisatrademarkofDeere&Company
