EthernetSwitch
EthernetswitchOCTOPUS5TX-EEChasbeenespecially
designedforuseinagriculturalenvironments.Itsupports
Ethernet10MBit/sandFastEthernet100MBit/s.Ethernet
switchmodulessupportswitchedEthernetnetworksin
accordancewithIEEEstandard802.3(10BASE-T)or
802.3u(100BASE-TX)usingcoppertechnology.Switch
modulesarefittedatinstallationsiteusingscrews.
OCTOPUS5TX-EECmoduleshavefive10/100Mbit/s
twistedpairports(10BASET/100BASE-TX,shieldedM12
connectors).ItispossibletoconnectuptofiveDTE(data
terminalequipment)orotherTP/TXnetworksegmentsto
theseportsusingtwistedpaircabling.TPportssupport
autonegotiation,autopolarity,andautocrossing.Ethernet
switchconformswithprotectionclassIP67(protection
againstshockandforeignparticles:dustproof,water
protection:protectedagainsttheeffectsattemporary
immersioninwater).ThisdeviceoffersanIP-based
QualityofService(QoS)function.
NOTE:EthernetSwitchisnotarequiredcomponent
oftheJDLink™System.
Ifequipped,thisdeviceisintendedtoallowEthernet
connectiontomodulartelematicsgateway(MTG)formore
thanonedeviceofferedbyJohnDeere.
PC19634—UN—15MAY14
EthernetSwitch
InstallationofthisEthernetSwitchrequiresahardware
installationkit.ContactyourJohnDeeredealerfor
purchasing,installation,andsupport.Installation
instructionsmaybefoundwiththehelpofyourJohn
Deeredealer.
JDLinkisatrademarkofDeere&Company
EthernetSwitchOperatingVoltage
EthernetSwitchOperatingVoltage
RatedVoltageRange
12—24VDC
MinimumVoltageRange
9VDC
MaximumVoltageRange
32VDC
