DEERE JDLink - Wireless Antenna Details; Satellite Module & Antenna; Satellite Antenna Details

PROOFPROOF
ComponentOverview
AE77568,00001F6-19-26MAY16-1/1
AE77568,00001F7-19-28JUN16-1/3
AE77568,00001F7-19-28JUN16-2/3
AE77568,00001F7-19-28JUN16-3/3
WirelessAntenna
Wirelessantennaisusedforcloseproximityorin-cab
wirelessconnectivity.
PC22092—UN—27JAN16
WirelessAntenna
SatelliteModuleandAntenna
SatelliteModule
NOTE:SatelliteModuleisnotofferedandusageis
notlegalinallregions.CheckwithyourJohn
Deeredealerforavailability.
OptionalSatelliteModuleisintendedtobeaslaveto
themodulartelematicsgateway(MTG),anddoesnot
functionproperlyasastandalone.Inlocationswith
poorcellcoverage,theSatelliteModulecanbeusedto
communicateinsteadoftheMTG.
PC12694—UN—19JUL10
SatelliteModule
TheSatelliteModuleutilizesasinglecoaxialTNC
connectorfortheantenna.TheconnectorisaTNC
receptacle.Thematchingconnectorisintegratedintothe
antennacable.TherearetwoLEDindicatorsontheend
fortheSatelliteModule.Thepowerindicatorisontheleft
(A)andthenetworkavailableindicatorontheright(B).
ThepowerindicatorLED(Green)glowswheneverthe
moduleiscommandedonbytheMTG,andthenetwork
indicatorLEDglows(Red)whentheSatelliteModule
detectsthesatellitenetwork.
A—PowerIndicatorB—NetworkAvailableIndicator
PC15191—UN—31MAY12
SatelliteModuleHeader
SatelliteAntenna
NOTE:SatelliteAntennaisnotofferedandusageis
notlegalinallregions.CheckwithyourJohn
Deeredealerforavailability.
TheSatelliteAntennasendsandreceivesmessagesfrom
theSatelliteModule.
PC12642—UN—11JUN10
SatelliteAntenna
