ComponentOverview
AE77568,00001F4-19-28JUN16-3/3
AE77568,00001F5-19-26MAY16-1/1
LEDstatusindicator(A)indicatesMTG’scurrentstate.
PC22663—UN—18MAY16
A—LEDStatusIndicator
LED
Frequency
LEDColorStatusSoftware
Booted
GPSCellularWireless/
Bluetooth®
OffN/ASleepmode/Off
Solid
AmberBootingup
FlashingMagenta
On
X
Solid
Magenta
On
XX
Flashing
GreenOn
XX
SolidGreenOn
XXX
FlashingBlue
On
XX
Solid
Blue
On
XXX
Alternating
Blue/Off/
Green/Off
On
XXX
Alternating
Blue/Green/
Blue/Green
On
XXXX
Solid
WhitePoweringdownX
FlashingRed
CANcommunicationerrorsincelaststartup
X
Solid
Red
Internalerror—replaceMTG
X
BluetoothisatrademarkofBluetoothSIG
Cellular,GPS,andWirelessAntenna
Thetwoantennasare:
•
HighPerformance:Providesthehighestgain,longest
range,andbestperformance.
•
LowProfile:HasashorterphysicalheightthanHigh
Performanceantenna.
Eachantennahasfourseparatecoaxialcables,twofor
cellular,oneforGPS,andoneforwireless.Allthecables
arebundledtogetherwithinasinglehousingforeaseof
mounting.
NOTE:Forbestfieldperformance,useHighPerformance
antennawheneverpossible.
GPSaccuracyisdegradedifthereisnota
clearviewofthesky.GPSsignalcannotbe
receivedinsideabuilding.
PC22042—UN—19JAN16
HighPerformanceAntenna
PC22043—UN—18JAN16
LowProfileAntenna
