4
Pre-Installation (continued)
HARDWARE INCLUDED
NOTE: Hardware shown to actual size.
AA BB CC
DD EE
FRONT
GND
FF
Part Description Quantity
AA Mounting bracket screw 2
BB Mounting bracket screw 2
CC Decorative screw (pre-installed) 2
DD Mounting bolt 1
EE Wire connector 1
FF Mounting bracket (not to scale) 1
PACKAGE CONTENTS
Part Description Quantity
A Lamp head 2
B Light xture 1
C Motion sensor 1
D Mounting plate 1
A
D
B
C
