Pre-Installation (continued)
HARDWARE INCLUDED
NOTE: Hardware shown to actual size.
AA BB CC DD
EE
FF
FRONT
GG
HH
Part Description Quantity
AA Rubber plug 1
BB Mounting bracket screw 2
CC Mounting bracket screw 2
DD Mounting bracket screw 2
EE Large mounting bolt (pre-installed) 1
FF Small mounting bolt 1
GG Mounting bracket (not to scale) 1
HH Mini screwdriver 1
PACKAGE CONTENTS
Part Description Quantity
A Lamp head 2
B Light xture 1
C Motion sensor 1
D
1-2-
asy Connect™
1
C
A
D
B
To Next Page
