10
Center speaker back panels
1 -
2 -
3 -
4 -
Status light: The light turns from red to blue when the speaker receives a signal
from your ampliier or receiver. For more information, see page 26.
Intelligent Bass Control knob: Increases or decreases the bass level. We recom-
mend starting at the 12-o’clock position when setting up the speaker.
Binding posts: Connect the speaker to your ampliier or receiver.
Power connector: Required to power the integrated subwoofer.
DM30
