The product must be connected
to the mains supply only by an
authorised and qualified person.
The product's warranty period
starts only after correct
installation.
Manufacturer shall not be held
responsible for damages arising
from procedures carried out by
unauthorised persons.
The power cable must not be
clamped, bent or trapped or come
into contact with hot parts of the
product.
A damaged power cable must be
replaced by a qualified electrician.
Otherwise, there is risk of electric
shock, short circuit or fire!
• Connection must comply with national
regulations.
• The mains supply data must correspond to
the data specified on the type label of the
product. Type label is at the rear housing of
the product.
• Power cable of your product must comply
with the values in "Technical specifications"
table.
Before starting any work on the
electrical installation, disconnect
the product from the mains supply.
There is the risk of electric shock!
Connecting the power cable
While performing the wiring, you must apply
with the national/local electrical regulations
and must use the appropriate socket outlet/
line and plug for oven.
In case of the product's power limits are out
of current carrying capability of plug and
socket outlet/line, the product must be
connected through fixed electrical installation
directly without using plug and socket outlet/
line.
1. If a power cable is not supplied
together with your product, a power
cable with a minimum requirement as
stated in the Technical specifications table
(Technical specifications, page ) in
accordance with the electrical installation at
your home must be connected to your
product by following the instructions in the
cable diagram.
If it is not possible to disconnect all poles in
the supply power, a disconnection unit with
at least 3 mm contact clearance (fuses, line
safety switches, contactors) must be
connected and all the poles of this
disconnection unit must be adjacent to (not
above) the product in accordance with IEE
directives. Failure to obey this instruction
may cause operational problems and
invalidate the product warranty.
Additional protection by a residual
current circuit breaker is
recommended.
2. Open the terminal block cover with a
screwdriver.
3. Insert the power cable through the cable
clamp below the terminal and secure it to
the main body with the integrated screw on
cable clamping component.
4. Connect the cables according to the
supplied diagram.
5. After completing the wire connections,
close the terminal block cover.
6. Route the power cable so that it will not
come into contact with the product and get
squeezed between the product and the
wall.

Defy DHD406A Specifications

General

Hob type	Ceramic
Product color	Black
Hob width size	- cm
Top surface type	Glass-ceramic
Appliance placement	Built-in
Cooking zone 1 type	Large
Cooking zone 2 type	Medium
Cooking zone 1 power	1800 W
Cooking zone 1 shape	Round
Cooking zone 2 power	1200 W
Cooking zone 1 diameter	180 mm
Cooking zone 1 position	Left front
Cooking zone 2 diameter	140 mm
Cooking zone 2 position	Right rear
Cooking zone 4 position	Right front
Number of cooking zones	4 zone(s)
Cooking zone 1 power source	Electric
Number of gas cooking zones	0 zone(s)
Built-in hood	No
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Connected load (gas)	- W
Connected load (electric)	6000 W
Control type	Touch
Display type	LED
Built-in display	Yes
Control position	Top front

Weight and Dimensions

Depth	510 mm
Width	650 mm
Height	55 mm
Installation compartment width	560 mm
Installation compartment depth (min)	490 mm
