Deger DEGERtracker D60H - Abridged Assembly Instructions for the Degertracker

24.03.2017 ASSEMBLY AND OPERATING MANUAL DEGERtracker D60H, D80, D100 Page 15
4 Abridged assembly instructions for the DEGERtracker
 Read the complete assembly instructions before starting assembly work
 Pay attention to all safety notes in the assembly instructions
1.
Erect the mast, install the supply lines
______________________________________________________________________________________
2.
Assemble the base frame
______________________________________________________________________________________
3.
Assemble the aluminum profiles to the base frame
______________________________________________________________________________________
4.
Mount the rotating head to the mast
______________________________________________________________________________________
5.
Assemble the elevation drive (EMO)
______________________________________________________________________________________
6.
Mount the solar modules on the aluminum profiles
______________________________________________________________________________________
7.
Assemble the MLD-control
Exemplary picture
DEGERtracker D100
Exemplary picture
DEGERtracker D100
Exemplary picture
DEGERtracker D100
Exemplary picture
DEGERtracker D100
