Yacht Manual DEHLER 32
28 - 67
Figure 9: Engine installation
Components
1 = Inboard diesel 2 = Saildrive 3 = Zinc ring
4 = Folding propeller 5 = Gasket 6 = Water collector
7 = Exhaust pipe 8 = Swan’s neck 9 = Outlet
IMPORTANT
Every time after starting the engine, you should check that cooling
water is being expelled with the exhaust fumes at the outlet!
4.1.2 Propeller
The yacht can be fitted with either a fixed propeller or a folding propeller.
IMPORTANT
In freshwater areas the zinc ring (3) must be replaced by
a magnesium ring.
