4.5 Onboard direct current system
The 12 V direct current system is responsible for the power supply for all general use
appliances. The 12 V – Plus load circuit can be switched off using the main switches next to
the port companion way and with the second master switch of the starter battery. The 12 V
power supply is comprised of the following main components/power supply sources.
Starter battery, consumer battery, motor generator (dynamo), and a battery charger
4.5.1 Master switches
The master switches of engine and of consumer batterie is mounted portside saloon sofa.
Figure 14: Master switches
1 = Master switch of engine
2 = Master switch of consumer
1
2
