Dehler 32 - Main Fuse Arrangement

Yacht Manual DEHLER 32
35 - 67
4.5.2 Arrangement of main fuses
The following main fuses are to be found under the saloon sofa port side behind the batteries
– depending on the equipment:
Figure 15: Main fuses
1= prefuse consumer 125A 2= General consumption 100A
3= Fuse charing curret 4= steady plus
Further distribution to the “general consumption” is via the power circuit distributor,
(switch board) above the starboard chart table.
4
1
2
3
1
