4.5.9 Terminals/Supplies
In the event of a fault it is necessary for its elimination to check whether the distribution
points are receiving any current. In this page we want to show you where the terminals and
supplies are positioned and how to find them on your boat.
1x6 for Mast under saloon sofa starboard
on main bulkhead
Distributor N° 1
1x6 under saloon cushion port side on
back bord galley
Distributor N°2
Distributor Nº 3 supply is on the side in
front off the chainplate support starboard
Figure 17: Terminals
