Yacht Manual DEHLER 32
48 - 67
Components
1 = Suction fitting 2 = Level indicator 3 = Holding tank
4 = Discharge pipe 5 = Quick shut-off valve outlet 6 = Tank ventilation
7 = Indicator 8 = Pump WC 9 = Intake hose
10 = Quick shut-off valve with sea water intake
IMPORTANT
Only open the quick shut-off valves for working the toilet installation!
