6
Heating
In order to make the sailing season less dependent on weather conditions and create a good
interior climate in the Dehler 34, a Webasto Air Top 3500D diesel heater can be installed.
The heater is installed at the starboard side aft in the stern storage space and is accessible
through the starboard locker seat. See the manufacturer’s Instructions for Use
Combustion air
The chimney for combustion air is installed
on the starboard side of the flat surface of
the stern.
6.1 Hot air
The air in the boat is drawn into and heated
in the heat exchanger via the heater intake.
Then the air is carried through a pipe system
to the four outlets in the cabin, bow, rear
cabin and shower room; the quantity of air
can be regulated at all hot air outlets, except
in the cabin.
Air distribution of the diesel heater
1 Hot air outlet bow
2 Hot air pipes
3 Hot air outlet cabin
4 Thermostat
5 Heater control
6 Hot air outlet shower room
7 Hot air outlet cabin
8 Diesel heater
9 Combustion air outlet
