4.2 Fresh water, drinking water, cold
The Dehler 34 has a polyurethane water tank, with a capacity of 160 l. It is installed under
bed in forward cabin. The filler cap is on the starboard on the coaming. An electric pressure
water pump with a secondary surge tank supplies the sink and the washbasin in the toilet area.
4.2.1 Cockpit shower
The fresh water tank also supplies the cockpit shower. The unit is installed on the surface aft.
Components
1. Ventilation starboard tank
2. Filler cap
3. Water tank
4. Sink bleed point
5. Pressure water pump
6. Surge tank
7. Hand washbasin bleed point
8. Cold water supply
9. Cockpit shower cold
Figure 12: Drinking water cold
