5. Access with the Service port
To configure the AMC 600 with the Service port, the development PC is connected with a Standard USB-B cable.
NOTICE
USB driver
The USB driver is automatically installed from Windows Update, when connecting the USB cable to the AMC 600. If no
connection to Windows Update is available the driver can be manually installed.
5.1 Manual installation
The USB serial driver for Microsoft Windows 10 is available for download at the DEIF FTP Server:
AWC_500/PC tools/USB_Service_Port_Driver/CP210xVCPInstaller_x64.exe
5.2 Create connection to the Service port
Use a "terminal program" for the serial connection.
The default communication parameters are:
Speed
115,200 bps
Data bits 8
Stop bits 1
Parity None
Flow control None
Example connection using PuTTY:
User's manual 4189341335A EN Page 24 of 33
