Delft Imaging Delft Light - Annex a Technical Specifications Delft Light

9
ANNEX A TECHNICAL SPECIFICATIONS DELFT LIGHT
Items
Specification
Electrical Power
1,35 kW @ 90 kV, 15 mA
Device power source
22.2 VDC (Battery)
22.2 VDC (Battery)
Battery
DC 59,2 V, Li+ battery
Frequency
120kHz
kV, mA
40-90 kV / 2 kV steps
X-ray exposure time
range [sec]
0.01 ~ 1 sec / 0,01 steps
Accuracy of
output
Accuracy of
radiation output
± 10%
X-ray tube
Model
Toshiba D – 0814
Inherent filtration
0.8mm AL
Focal spot
0.8 x 0.8mm
Anode heat storage
10.000 HU
Total filtration
(HVL)
Tube Inherent
Filtration
0.8mm AL
Beam limiting device
Addition
Filtration
0.5mm AL
Size
22(H)x18(W)x25(H) cm
Weight
7 kg
Detector
CXDI 702-c
Effective pixel area
2240 x 2992
A/D conversion
14/16 bits
Preview time
< 3 sec
DQE
85%
Size
35 x 43 cm
Weight
3 kg
